5. Remove the outer air cleaner (7).
6. Remove the screw/washers (6) and remove
the air cleaner assembly from the air cleaner
holder (8).
7. Remove the inner air cleaner (9) and air
cleaner screen (10) from the air cleaner guide
(11).
8. Remove the air cleaner screen from the inner
air cleaner.
(6)
(6) Screw/washer
(7) (8) (9) (10) (11)
(7) Outer air cleaner
(8) Air cleaner holder
(9) inner air cleaner
(10) Air cleaner screen
(11) Air cleaner guide
121
