1. GENERAL INFORMATION
1-14
MXU 500
Item Q‘ty
Thread
dia.
(mm)
Torque
K
g
f-
m
(
N-m,
lbf-ft)
Remarks
STEERING SYSTEM:
Handlebar holder bolt
Steering bracket
Steering column nut
Tie-rod ball joint nut
WHEEL:
Front wheel nut
Rear wheel nut
SUSPENSION:
Front:
Front swing arm bolt/nut
Knuckle ball joint nut
Front shock absorber mount bolt/nut
Rear:
Rear shock absorber mount bolt/nut
Right pivot bolt
Left pivot bolt
Left pivot lock nut
Axle housing mounting bolt/nut
BRAKE SYSTEM:
Front brake disc bolt
Rear brake disc bolt
Brake caliper mounting bolt
Brake hose oil bolt
Master cylinder holder bolt
Brake pad mounting bolt
Bleed valve nut
Delay valve mounting bolt
Delay valve plug
4
2
1
4
8
8
6
4
4
4
1
1
1
8
8
4
8
10
4
8
5
2
1
8
8
14
10
10
10
10
12
10
10
30
30
30
10
8
8
8
10
6
8
6
6
20
2.5 (25, 18)
2.2 (22, 16)
7 (70, 50)
2.1 (21, 16)
6.5 (65, 46)
6.5 (65, 46)
4.5 (45, 32)
3 (30, 22)
4 (40, 29)
4 (40, 29)
11.8 (118, 85)
1.1 (11, 8)
11.8 (118, 85)
5.5 (55, 40)
3.5 (35, 25.2)
3.5 (35, 25.2)
3.2 (32, 24)
3.5 (35, 25)
1.2 (12, 8.6)
1.8 (18, 13)
0.6 (6, 4.32)
1.2 (12, 8.6)
5 (50, 36)
Castle nut
Castle nut
OFF ROAD: 4 Q’ty
ON ROAD only
ON ROAD only
