2. FRAME COVERS/EXHAUST MUFFLER
2-5
MXU 500
Remove the two mounting bolts from the
front cargo rack right/left side under front
fender.
Remove the two mounting bolts from front
cargo rack, remove the front cargo rack.
Installation is in the reverse order of
removal.
FRONT CARRIER COVER
REMOVAL/INSTALLATION
Remove the four bolts from the front carrier
cover, then remove the front carrier cover.
Installation is in the reverse order of
removal.
