3. INSPECTION/ADJUSTMENT
3-10
MXU 500
Measure the spark plug gap between the
center and side electrodes with the feeler
gauge.
If necessary, adjust the gap by bending the
side electrode carefully.
Spark plug gap:
0.6－0.7 mm (0.024－0.028 in)
Install the spark plug in the cylinder head
and hand tighten, then torque to the
specification.
Torque: 1.2 kgf-m (12 N-m, 8.6 lbf-ft)
Install the spark plug cap.
Install the removed parts in the reverse
order of removal.
