(17) Reservoir water tank
(18) Front brake fluid reservoir
(19) Right rearview mirror
(20) Fuel valve
Brake pedal fluid reservoir
(24) Seat lock lever
(25) Oil level inspection window
(21) Recoil starter
(22) Seat
(23)
(20)
(22)
(23) (24)
(21) (17)(18)
(19)
(25)
