(34 Right footpeg
(35) Owner’s manual storage
)
(36) Front cargo rack
(37) Ignition switch
(38) Rear parking brake lever
(39) Left footpeg
(40) Rear cargo rack
(41) Fuel fill cap
(42) Choke knob
(43) Rear brake pedal
(44) Flag pole bracket
16
(41) (42) (43)(40)
(35)
NOTE:
The machine you have purchased may differ
slightly from those shown in the figures of this
manual.
(44)
(37) (36)(39) (34)(38)
