7. ENGINE REMOVAL/INSTALLATION
7-11
MXU 500
Install the rear cooling duct.
Install the removed parts in the reverse
order of removal.
Route the water hoses, wire and cable
properly (refer to the “CABLE &
HARNESS ROUTING” section in the
chapter 1).
Adjusting the following items:
Ɣ Engine oil (refer to the “ENGINE OIL”
section in the chapter 3).
Ɣ Engine coolant (refer to the “COOLANT
REPLACEMENT” section in this
chapter).
Make sure the lug on the left crankshaft
case into the cutout on the rear cooling
duct.
＊
