11.FINAL REDUCTION/
TRANSMISSION SYSTEM
11-28
MXU 500
ASSEMBLY/INSPECTION
Inspect the gear teeth.
Blue discoloration/pitting/wear ĺ Replace.
Inspect the mated dogs.
Rounded edges/cracks/missing portions
ĺ Replace.
Washe
r
High Drive Gea
r
Washe
r
High/Low Gear Clutch dog
Clip
Washe
r
Low Drive Gea
r
Countershaf
t
Reverse Drive Gea
r
Washe
r
Clip
Reverse Gear Clutch dog
Clip
Stopper Wheel
Clip
