14. FRONT WHEEL/FRONT SUSPENSION
STEERING SYSTEM
14-5
MXU 500
FRONT WHEEL HUB
REMOVAL/INSPECTION/
INSTALLATION
REMOVAL
Place the machine on a level place.
Remove the front wheel (
refer to the
“
FRONT WHEEL
REMOVAL/INSPECTION/
INSTALLATION” section in this chapter)
Elevate the front wheels by placing a
suitable stand under the frame.
Remove the cotter pin.
Apply the front brake and then remove nut,
washer and front wheel hub.
INSPECTION
Check the wheel hub for cracks or deamage.
Check the wheel hub splines for wear or
damage.
Support the machine securely so there
is no dan
