14. FRONT WHEEL/FRONT SUSPENSION
STEERING SYSTEM
14-31
MXU 500
Remove the cotter pin and nut from the
steering column under the frame body, then
remove steering column.
Remove the collar and dust seal.
Remove the dust seal.
Remove the snap ring.
Collar Dust Seal
Snap Ring
Dust Seal
