16. BRAKE SYSTEM
16-12
MXU 500
Connect a transparent hose to the right
caliper bleed valve and then loosen the
bleed valve nuts.
Use the syringe to draw brake fluid into it
until there is no air bubbles in the
transparent hose.
Then, tighten the bleed valve nut.
Torque: 0.6 kgf-m (6 Nm, 4.32 lbf-ft)
Connect a transparent hose to the left
caliper bleed valve and then loosen the
bleed valve nuts.
Use the syringe to draw brake fluid into it
until there is no air bubbles in the
transparent hose.
Then, tighten the bleed valve nut.
Torque: 0.6 kgf-m (6 Nm, 4.32 lbf-ft)
Recommended Brake Fluid: DOT-4
xWhen drawing brake fluid with the
syringe, the brake fluid level should be
kept over 1/2 of the brake reservoir
height.
xUse only the recommended brake fluid.
＊
