204 X75HD/X75SD Installation and Operation Manual
Appendix A: Cables and Pinouts
Table A-4 describes each pin on the X75OPTCAB-MULTI DB-26M
connector and its connection type.
Table A-4. X75OPTCAB-MULTI Pinout Descriptions
Pin Number Connection Type Description
1 BNC-Gnd Sync/composite out ground
2 BNC Sync/composite out signal
3 BNC-Gnd Blue out ground
4 BNC Blue out signal
5 BNC-Gnd Green out ground
6 BNC Green out signal
7 BNC-Gnd Red out ground
8 BNC Red out signal
9 4-Pin DIN-1-Gnd
4-Pin DIN-2-Gnd
S-video (Y) ground
S-video (C) ground
10 XLR-2 Future use
11 XLR-1-Gnd Future use
12 BNC-Gnd SDTV audio delay ground
13 BNC-Gnd HDTV audio delay ground
14 RCA-Gnd GPI out 1 ground
15 RCA Gnd GPI out 2 ground
16 RCA Gnd GPI in 1 ground
17 RCA Gnd GPI in 2 ground
18 4-Pin DIN-4 S-video (C) out
19 XLR-3 Future use
20 BNC SDTV audio delay out
21 BNC HDTV audio delay out
22 RCA GPI out 1
23 RCA GPI out 2
24 RCA GPI in 1
25 RCA GPI in 2
26 4-Pin DIN-3 S-video (Y) out
