X75SD/X75HD Installation and Operation Manual 19
Chapter 1: Introduction
X75OPT-STR Optional video and audio streaming
for Ethernet monitoring (SDTV and
down-converted HDTV)
Streaming submodule, field-upgradable
X75-RCP Remote control panel for
X75HD/X75SD
Can control DPS-475/575
Cable Options
X75OPTCAB-MULTI Cable set for multi input/output
connectors
• Sync/comp out
• Blue, Green, and Red out
• Y/C out
• SDTV and HDTV audio delay
• GPI1 and GPI2 in
• GPI1 and GPI2 out
1 ft (30 cm) multi I/O breakout cable with the
following connector types:
• DB26(M) to 6 x BNC(F), 1 x XLR(F), 1 x
MiniDin4(F), and 4 x RCA(F)
X75OPTCAB-DVI Cable for DVI-D single-link output DVI-D to DVI-D (digital-single link) cable
X75OPTCAB-8-C 1 cable set for 8-channel audio
synchronizer, with the following
unbalanced coax AES connectors:
• AES1, AES2, and DARS in
• AES1 and AES2 out
1 ft (30 cm) breakout cable with the
following connector types:
• DB26(M) to 5 x BNC(F)
X75OPTCAB-8-X 1 cable set for 8-channel audio
synchronizer, with the following
balanced XLR AES connectors:
• AES1, AES2, and DARS in
• AES1 and AES2 out
1 ft (30 cm) breakout cable with the
following connector types:
• DB26(M) to 3 x XLR(F)
• 2 x XLR(M)
X75OPTCAB-8-CX 1 cable set for 8-channel audio
synchronizer, with the following
unbalanced coax AES and XLR
connectors:
• AES1, AES2, and DARS in
• AES1 and AES2 out
1 ft (30 cm) breakout cable with the
following connector types:
• DB26(M) to 5 x BNC(F)
•3 x XLR(F)
•2 x XLR(M)
Table 1-2. X75HD/X75SD System Options(Continued)
Product Code Description Major Features
To Next Page
