20 X75HD/X75SD Installation and Operation Manual
Chapter 1: Introduction
X75OPTCAB-16-C 2 cable sets for 16-channel audio
synchronizer, with unbalanced coax
AES connectors
• AES1, AES2, and DARS in
• AES1 and AES2 out
• AES3, AES4, and AES5 in
• AES3, AES 4, and AES 5 out
2 X 1 ft (30 cm) breakout cables with the
following connector types:
• DB26(M) to 5 x BNC(F)
• DB44(M) to 6 x BNC(F)
X75OPTCAB-16-X 2 cable sets for 16-channel audio
synchronizer, with balanced XLR
AES connectors
• AES1, AES2, and DARS in
• AES1 and AES2 out
• AES3, AES4, and AES5 in
• AES3, AES 4, and AES 5 out
2 X 1 ft (30 cm) breakout cables with the
following connector types:
• DB26(M) to 3 x XLR(F) and
2 x XLR(M)
• DB44(M) to 3 x XLR(F) and
3 x XLR(M)
X75OPTCAB-16-CX 2 cable sets for 16-channel audio
synchronizer, unbalanced coax AES
and balanced XLR AES
• AES1, AES2, and DARS in
• AES1 and AES2 out
• AES3, AES4, and AES5 in
• AES3, AES 4, and AES 5 out
2 X 1 ft (30 cm) breakout cables with the
following connector types:
• DB26(M) to 5 x BNC(F), 3 x XLR(F), and
2 x XLR(M)
• DB44(M) to 6 x BNC(F), 3 x XLR(F), and
3 x XLR(M)
Table 1-2. X75HD/X75SD System Options(Continued)
Product Code Description Major Features
