54 X75HD/X75SD Installation and Operation Manual

Chapter 3: Module and Back Panel Descriptions

Figure 3-2. Jumper Locations for X75OPT-AS-16 and X75OPT-AS-8 Modules

Jumpers for

outputs 4, 3, 2, 1

Jumpers for

inputs 4, 3, 2, 1

J1/9J2/10J3/11

J4/12
