Chapter 3: Displays
Software Version 3.05
43
?
HINT: In the Effect display, use the Position Keypad as follows:
1. Use the Up and Down arrow keys to select individual steps in
the effect currently being edited. The Down Arrow key will
also create steps
2. Use the [NEXT] and [LAST] keys to view different effects.
3. Use the [PAGE UP] and [PAGE DOWN] keys to view steps
that are out of view of the display
Status Bar: The Status Bar is located just below the main information
area. The Status Bar contains the following fields for information:
?? Effect: shows the number of the current effect being viewed and edited.
?? Name: shows the name of the current effect.
?? Mode: shows the effect mode, either "Pile-on", or "Take Control".
?? Cycle Time: shows the amount of time it takes to execute all the steps
of the effect once (the sum
of all the Dwell Times).
Pattern Bar: The Pattern Bar is directly below the Status Bar, and shows
the choice of patterns available for the current effect. Selected patterns appear
as black text in a gray background. More than one pattern may be selected
simultaneously. The choice of effect patterns available in the Pattern Bar is
listed below:
?? Positive / Negative
?? Forward / Reverse
?? Alternate
?? Build
?? Bounce
?? Random
Command Line / Command Line History: Directly below the
Status Bar are the Command Line History and the Command Line. The
Command Line displays the command currently being entered. The Command
Line History shows the last command executed.
Soft Key Labels: The Soft Key Labels are located directly below the
Command Line. The Soft Key Labels describe the function of each soft key.
The function commands are executed by pressing one of the soft keys, (S1) -
(S10), on the console. The functions of the soft keys change for each display.
To Next Page
