Chapter 3: Displays
Software Version 3.05
47
Status Bar: The Status bar is located just below the channel and level
information in the main part of the display. The Status Bar contains the
following fields of information:
?? Cue: shows the current preview cue being edited, and the cue attributes.
?? Stage Cue: shows the last cue executed on stage.
?? Next Cue: shows the next cue number to be executed when the GO
button is pressed.
?? Mac Pg: shows the number of the macro page (0 - 9) currently being
accessed.
Command Line / Command Line History: Directly below the
Status Bar are the Command Line History and the Command Line. The
Command Line shows the command currently being entered. The Command
Line History shows the last command executed.
Track Mode: The current Track mode (Cue Only, Tracking, or Clean Up)
appears at the far left of the Command Line.
Soft Key Labels: The Soft Key Labels are located directly below the
Command Line. The Soft Key Labels describe the function of each soft key.
The function commands are executed by pressing one of the soft keys, (S1) -
(S10), on the console. The functions of the soft keys change for each display.
Tracksheet Display Paging Rules: The rules for paging through
the Tracksheet display are as follows:
1. To scroll the list of cues up or down one line at a time, press the Up
and Down Arrow keys.
2. To scroll the list of cues up or down one page at a time, press the
[PAGE UP] and
[PAGE DOWN] keys.
3. To select a different cue for editing, press the [NEXT] and [LAST]
keys.
- or -
Press [CUE] [#] [ENTER].
4. To show a different range of channels across the top of the display,
press the Left and Right Arrow keys.
? NOTE: When you press [CUE] [#] [ENTER], a new cue is created if
the cue does not already exist.
