Connector Connects to Pin no. Signal
JMTR1 Motor (main) 1 MAIN_HALL_U_CN
2 MAIN_HALL_V_CN
3MAIN_HALL_W_CN
4MAIN_FG_CN
5Ground
65V_ENG
7V_MAINC1_U
8V_MAINC1_V
9V_MAINC1_W
JRESET1 not used ‑‑ not used
JCVR1 Cover open 1 V_5V_INDEX
2S_INDEX_C
3Ground
JINDEX1 Sensor (stack height) 1 V_5V_INDEX
2S_INDEX_C
3Ground
JSTAG1 Staging solenoid ‑‑ not used
JFUSB1 Thumb drive 1 V_FUSB_L
2 USB_FRONT_N
3 USB_FRONT_P
4NC_JFUSB_P4
5Ground
JSPKR1 External speaker 1 SPEAKER1
2SPEAKER2
JHOME1 Sensor (flatbed home) 1 +3V_HOME
2Ground
3BHOME_FBR
JVIP2 Secure element SIM 1 G_TXD
2 +3.3v
3G_TXD
4Ground
5G_CS
6G_RXD
7018
Component locations
