Connector Connects to Pin no. Signal
JFBM1 Motor (flatbed) 1 FBM_A-
2FBM_A+
3FBM_B+
4FBM_B-
JFBCIS1 Flatbed CIS FFC N/A N/A
JADF1 ADF FFC N/A N/A
J30 Security jumper 1 +3.3V
2Ground
3Ground
JBINS1 Sensor (bin full) 1 V_3.3V_BINS
2PAPER_FULL_S_R
3Ground
4Ground
JT_PRE1 Sensor (tray present) 1 V_3.3V_TRAY1
2S_TRAY1_C
3Ground
JACM1 Sensor (ACM) 1 +5V_ENG
2 S_ACM_SEN_C
3Ground
JPHONE2 not used ‑‑ ‑‑
JUICC1 Control panel FFC N/A N/A
JBSCIS1 Backside CIS FFC N/A N/A
JSTAPL1 Stapler unit 1 +24V_F_OPT
2 S_STP_TXR
3Ground
4 S_STP_RXR R161
5Ground
6Ground
7Ground
7018
Component locations
