LSIS XDL-L7SA002X User Manual

4. Parameters
4-46
4.2.8 Operation Handling Parameter
“**” Modification is not possible with the servo on & Power reset parameter.
“*” Parameter that cannot be modified with the servo on
Parameter Unit Initial
Details
Code Name
Minimu
m
Maximu
m
Cn-00
Manual JOG operation - -
The drive performs manual JOG operation
by itself.
(Refer to “Chapter 5 Handling and
Operation.”)
 [MODE]: Finish
 [UP]: Forward rotation (CCW)
 [DOWN]: Reverse rotation (CW)
 [SET]: Servo ON / OFF
Related parameters are as follows:
 [P3-08]: Speed command acceleration
time
 [P3-09]: Speed command deceleration
time
 [P3-10]: Speed command S-curve
 [P3-11]: Speed operation pattern
 [P3-12]: JOG operation speed
Operate regardless of the contact input
status of CN1.
(Details: Refer to “4.4.5 Speed Operation
Parameter Setting.”)
(Details: Refer to "5.2 Handling.")
Jog - -
Cn-01
Program JOG operation - -
Continuously operates according to the
program already set.
 [SET]: Program JOG run or stop
Related parameters are as follows:
 [P3-08]: Speed command acceleration
time
 [P3-09]: Speed command deceleration
time
 [P3-10]: Speed command S-curve
 [P3-11]: Speed operation pattern
 [P3-13~16]: Program operation speed 1
to 4
 [P3-17~20]: Program operation time 1 to
4
Operate regardless of the contact input
status of CN1.
(Details: Refer to “4.4.5 Speed Operation
Parameter Setting.”)
(Details: Refer to "5.2 Handling.")
Program jog
- -
Cn-02
Alarm reset - -
Reset the alarm that went off.
(Details: Refer to "5.2 Handling.")
Alarm reset - -
