5. Handling and Operation
5-3
5.2 Handling
5.2.1 Manual JOG Operation [Cn-00]
The drive performs manual JOG operation by itself.
1. Press [SET] in [Cn-00] and [JoG] is displayed.
2. Press [SET] and [SV-on] is displayed and the servo turns on for operation.
If an alarm triggers, check wiring and other possible causes before restarting.
3. Press and hold [UP] and the motor turns forward (CCW) at the JOG operation speed [P3-12].
4. Press and hold [DOWN] and the motor turns counterclockwise at the JOG operation speed [P3-12].
5. Press [SET] again and the manual JOG operation finishes and the servo turns off.
6. Press [MODE] for a while and then you return to the parameter screen [Cn-00].
Related Parameters Speed Initial
[P3-08] Speed command acceleration time [ms] 0
[P3-09] Speed command deceleration time [ms] 0
[P3-10] Speed command S-curve time [ms] 10
*[P3-11] Speed operation pattern 0
[P3-12] JOG operation speed [RPM] 500
The parameter marked with “*” cannot be modified when the servo is on.
