1. Product Components and Signals
2-1
1. Product Components and Signals
1.1 Product Components
1.1.1 Product Verification
1. Check the name tag to verify that the product received matches the model ordered.
 Does the format of the servo drive's name tag match?
 Does the format of the servo motor's name tag match?
2. Check the product and options.
 Are the type and length of the cables correct?
 Does the regenerative resistance conform to the required standard?
 Is the shape of the shaft end correct?
 Is there any abnormality when the oil seal or brake is mounted?
 Are the gearbox and the gear ratios correct?
 Is the encoder format correct?
3. Check the exterior of the device.
 Is there any foreign substance or humidity?
 Is there any discoloring, contamination, damage or disconnection of wires?
 Are the bolts at joints fastened sufficiently?
 Is there any abnormal sound or excessive friction during rotation?
 Servo Drive Product Format
Series
Name
Communication
Type
Input
Voltage
Capacity Encoder Type Option
Servo
Series
S: Standard I/O
type
N: Network type
A: 220 VAC
B: 400 VAC
001: 100 W 050: 5.0 kW
002: 200 W 075: 7.5 kW
004: 400 W 110: 11.0kW
008: 750 W 150: 15.0kW
010: 1.0 kW
020: 2.0 kW
035: 3.5 kW
A: Parallel
(Pulse type)
B: Serial
(communication
type)
Exclusive
Option
XDL-L7 S A 004 A AA
