LSIS XDL-L7SA002X

5. Handling and Operation
5-21
5.2.16 Instantaneous Maximum Load Factor
Initialization [Cn-15]
Reset the instantaneous maximum load factor to 0.
[Example of initializing the instantaneous maximum load factor]
Order Loader Displays Keys to Use What to Do
1 Press [MODE] to display [Cn-00].
2
Press [UP] or [DOWN] to move to
[Cn-15].
3
Press [SET] to enter instantaneous
maximum load factor initialization.
4
Press [SET] and the current
maximum load factor is displayed.
5
or
Press [UP] and the forward direction
maximum load factor is displayed.
Press [DOWN] and the reverse
direction maximum load factor is
displayed.
6
or
Press [SET] and the instantaneous
maximum load factor is reset.
[Done] is displayed.
If you press [MODE] and will not
reset.
7
Press [MODE] for a second to return
to [Cn-15].
※ “ ” indicates flickering.
