MERLIN LEGEND Communications System Release 6.1
Feature Reference 555-661-110
Issue 1
August 1998
Features
Page 88Basic Rate Interface (BRI)
Basic Rate Interface (BRI) 3
At a Glance 3
Users Affected Telephone users, operators, digital data users
Reports Affected System Information (
6\V6HWXS), BRI Information
Modes Key, Hybrid/PBX
Telephones All (display support on MLX telephones only)
System Programming
800 NI-BRI Module Specify 800 NI-BRI modules that provide primary, secondary,
and tertiary clock synchronization and source-of-clock
synchronization; also activate/deactivate clock:
●
/LQHV7UXQNV→More→&ORFN6\QF
Assign telephone numbers (SPID and DN) to BRI lines:
●
/LQHV7UXQNV→More→%5,→63,''1→ 63,'→(QWHU→
'1→(QWHU
Specify BRI timer settings:
●
/LQHV7UXQNV→More→%5,→7LPHUV
Maximums
BRI modules 5
Factory Settings
Systemwide Clock
Synchronization Source
Primary Clock
Clock
BRI
Service Profile Identifier
(SPID) assigned to BRI
line
Loop (not definable by system manager)
First port in service on an 800 NI-BRI module, or first 100D
module in service in control unit
Active
0 digits
Directory Number (DN)
assigned to BRI line
0 digits
Timer and counter
thresholds for all BRI
ports in system
T200 Timer
T203 Timer
T303 Timer
T305 Timer
T308 Timer
1,000 ms (range 500–5,000 ms, increments of 500 ms)
33 seconds (range 10–255 seconds, increments of 1 second)
4 seconds (range 2–10, increments of 1 second)
30 seconds (range 2–60, increments of 1 second)
4 seconds (range 2–10, increments of 1 second)
