MERLIN LEGEND Communications System Release 6.1
Feature Reference
555-661-110
Issue 1
August 1998
Features
Page 252Display
Figure 16. 2-Line Display Home Screen
When the extension is idle, Line 2 of the Home screen shows the date and time. If
the timer is running or there is a programmed Alarm button, this information is also
shown on Line 2.
On an MLX-20L telephone, two pages of listings from the user’s Personal
Directory (a total of 16 entries) can be programmed to appear on the Home
screen. The Queued Call Console does not have this capability.
When a user activates features, information on the Home screen is replaced by
prompts and feedback. In general, prompts appear on Line 1, and feedback
appears on Line 2.
Figure 17. 7-Line Display Home Screen
Menu Screen
The Menu screen, illustrated in Figures 18 and 19, lists features and functions that
are used through the display, such as Alarm Clock and Directories. For everyone
with displays, except QCC operators, the Menu screen also provides access to
the extension programming function used to program the extension.
Press the Menu button next to or below the display to access the Menu screen. To
access additional menu choices on the 2-line display, press the More button. After
you make a selection from the menu by pressing the button next to the selection
on a 7-line screen or below the selection on a 2-line screen a submenu, feature
screen, or data entry screen appears. When programming is complete, the Menu
screen reappears. To exit from the Menu screen, press the Home button.
Home
Menu
Inspct
More
IN CONFERENCE
MAR 15
12:30
Inspect Mode
Home
Menu
More
Inspct
IN CONFERENCE
12:30
AIRLINE
HOTEL
TRAVEL AGNT
BANK
STEVENSON
ANDERSON
EPSTEIN
CAHALL
Next Page
Show Number
MAR 15
To Next Page
