Lucent Technologies MERLIN LEGEND Release 6.1 User Manual

MERLIN LEGEND Communications System Release 6.1
Feature Reference 555-661-110
Issue 1
August 1998
Sample Reports
Page F-14DS1 Information Report
F
806 4/ 2 No Remote Yes Long 4
807 4/ 3 No Remote Yes Long 4
808 4/ 4 No Remote Yes Long 4
809 5/ 1 No Remote 890 Yes Long 4 10
810 5/ 2 No Remote Yes Long 4
811 5/ 3 No Remote Yes Long 4
812 5/ 4 No Remote Yes Long 4
813 5/ 5 No Remote Yes Long 4
814 5/ 6 No Remote Yes Long 4
815 5/ 7 No Remote Yes Long 4
816 5/ 8 No Remote Yes Long 4
817 6/ 1 Dedicated Yes Long 42 4
. . . . . . . . . .
. . . . . . . . . .
912 10/1 No Remote Yes Long 4 12 OUT
913 10/2 No Remote Yes Long 4 13 BOTH
DS1 Information Report 55
3ULQW0HQX2SWLRQ 7,QIR
DS1 SLOT ATTRIBUTES
Slot Type Format Supp Signal LineComp ClkSync Src Active
2 T1 D4 ZCS Rob Bit 1 Prim Loop Yes
3 T1 D4 ZCS Rob Bit 1 None Local Yes
PRI Information Report 55
Print Menu Option: 35,,QIR
Sections: Network Selection, Special Service, Call-by-Call and Dial
Plan Routing Tables; PRI Information
Slot 5 Switch: DMS-100
Slot 11 Switch: Legend-PBX
Slot 12 Switch: Legend-PBX
System: By line
BchnlGrp #: Slot: TestTelNum: NtwkServ: Incoming Routing:
5 5 CallbyCall By Dial Plan
Channel ID: 23 22 21 20 19 18 17 16 15 14
13 12 11 10 9 8 7 6 5 4
3 2 1
Line PhoneNumber NumberToSend
