MERLIN LEGEND Communications System Release 6.1
Feature Reference
555-661-110
Issue 1
August 1998
Features
Page 32Alarm
Alarm 0
At a Glance 0
Description 0
Alarms provide either a visible or audible indication when the system detects a
problem that needs immediate attention.
■ Alarm Button. A programmed button on Direct-Line Consoles (DLCs) and
a factory-set button on QCCs that alerts an operator to system problems.
The red LED next to the Alarm button on the operator console lights when
the system detects a problem (such as a problem with one of the
lines/trunks or some other system error) that requires immediate attention.
It remains on until the problem is corrected.
■ Maintenance Alert. An alert device such as a bell or strobe light
connected to the line or trunk designated as a maintenance alarm jack. The
device rings or lights when the system detects a problem.
The red LED on the processor module turns on when the system detects a
problem that requires immediate attention. It remains lit until the problem is
corrected.
The red LED on some modules turns on when the system detects a
module-related problem, for example, a loss of service on a 100D module.
Considerations and Constraints 0
As soon as the system detects a problem, the red LED next to the Alarm button
turns on and/or the maintenance alert sounds or flashes.
All system operator consoles with an Alarm button receive the indication.
Users Affected Operators
Reports Affected Extension Information
Mode All
Telephones System operator consoles only (QCC or DLC)
Programming Code
MLX Display Label
$ODUP>$ODUP@
System Programming
$X[(TXLS→0DLQW$ODUPV
Hardware Alert device (bell or strobe) for Maintenance Alert
