MERLIN LEGEND Communications System Release 6.1
Feature Reference
555-661-110
Issue 1
August 1998
Features
Page 225Direct Station Selector
Table 13. LED Meanings for Normal Call-Handling Operation
LED Status Extension Type Meaning
Off Individual The person is not on the telephone and is not using Do
Not Disturb.
Line/Trunk number The line/trunk is not in use. The LED is always off for a
DID trunk or a Switch 56 trunk on a DLC.
Pool dial-out code At least one line/trunk is available for making an
outside call.
Calling group The calling group queue is below the programmed
threshold (in Release 5.0 and later systems, below
Threshold 1).
Paging group The group is available for making a group
announcement.
Operator Park Zone A call is not parked on this park zone code.
ARS, Remote
access, LDN
Not applicable, red LED is always off.
On
â–
Individual The person is on the telephone or has activated the
Do Not Disturb feature.
Line/trunk number The line/trunk is in use. No indication appears for a
busy DID trunk or Switch 56 trunk on a DLC.
Pool dial-out code No lines/trunks are available in this pool for outside
calls.
Calling group The calling group queue is at or above the allowable
threshold (in Release 5.0 and later systems, at or
above Threshold 3).
Paging group An announcement is being made to a paging group.
Operator Park Zone A call is parked in this park zone.
ARS, Remote
Access, LDN
Not applicable, red LED is always off.
Fast flashing Individual The person is calling the system operator position.
Slow flashing Individual A call transferred by the system operator to the
extension is returning.
Calling group The group queue is at or above Threshold 1 and below
Threshold 3 (Release 5.0 and later systems).
Line/trunk number A call is ringing on this line/trunk. No indication
appears for a busy DID trunk or Switch 56 trunk on a
DLC.
