Figure 7. Group Coverage Only or All Individual Coverage Receivers Unavailable
(Release 4.0 and Prior Systems)
2-ring delay
(Delay Ring Interval)
First
audible
ring
Receiver A
Ring option:
Immediate
Receiver B
Ring option:
Delay
Settings:
Delay Ring Interval = 2 rings
Secondary Delay Interval = 3 rings
Green LED
flashes
immediately
Green LED
flashes
immediately
Red
LED
on
Green LED
flashes
immediately
Group Cover
Group 1
Group Cover
Group 1
Call 1
Sender
Extension 18
Member of Coverage group 1
Immediate ring
Immediate
ring
Immediate
ring when operator
is available
Immediate
ring when operator
is available
3-ring
(Coverage Delay
Interval)
QCC
queue
QCC system
operator
Ring option: N/A
QCC system
operator
Ring option: N/A
First
audible
ring
Green LED
flashes
immediately
Call 1
Sender
Extension 25
Member of Coverage group 2
Eligible Call
QCC
queue
Immediate
ring when operator
is available
3-ring
(Coverage Delay
Interval)
Calling Group
member
Ring option: N/A
First
audible
ring
Green LED
flashes
immediately
SA Ring
Sender
Extension 20
Member of Coverage group 3
Eligible Call
Calling
Group
queue
