MERLIN LEGEND Communications System Release 6.1

Feature Reference

555-661-110

Issue 1

August 1998

Features

Page 513Primary Rate Interface (PRI) and T1

Figure 38. PRI Call Processing (Non-Tandem Only)

ARS=Automatic Route Selection DPR=Dial Plan Routing Table NS=Network Selection Table

CBC=Call-by-Call Services Table DPT=Direct Pool Termination SA=System Access

PL= Personal Line SSS=Special Services Selection Table

Foreign Exchange

CBC

Incoming

call

Outgoing

call

DPR

ARS

POOL

SSS

B-Channel Group

(SA)

(DPT)

(SA) (PL) (PL)

(SA)
