MERLIN LEGEND Communications System Release 6.1
Feature Reference
555-661-110
Issue 1
August 1998
Features
Page 710Uniform Dial Plan Features
Uniform Dial Plan Features 48
At a Glance 48
Users Affected All
Reports Affected Non-Local Dial Plan, Extension Information
Modes Hybrid/PBX
Telephones All
System Programming Assign extension number ranges for non-local dial plan
extensions:
●
6\V5HQXPEHU→1RQ/RFDO8'3→Dial no. of first extension in
range
→(QWHU→Dial no. of last extension in range→
(QWHU→Dial no. of dial digits in extension range→ (QWHU
Dial no. of pattern for extension range→ (QWHU →([LW→([
LW
→([LW
Delete extension number ranges for non-local dial plan
extensions:
●
6\V5HQXPEHU→1RQ/RFDO8'3→Dial no. of first extension in
range
→(QWHU→'HO5DQJH→([LW→([LW
Specify UDP routes:
●
7DEOHV→8'35RXWLQJ→Dial pattern no.→(QWHU→Dial
route no.
→(QWHU→3RRO→Dial pool dial-out code→
(QWHU→([LW→([LW→([LW→([LW
Specify FRLs for UDP routes:
●
7DEOHV→8'35RXWLQJ→Dial pattern no.→(QWHU→Dial
route no.
→(QWHU→)5/→Dial restriction level→
(QWHU→([LW→([LW→([LW→([LW
Specify how many dialed digits should be absorbed (not sent
over the trunk) by the system when a UDP call to a non-local
extension is made on an identified UDP route:
●
7DEOHV→8'35RXWLQJ→Dial pattern no.→(QWHU→Dial
route no.
→(QWHU→$EVRUE→Press Drop→Dial number of
absorption digits
→ (QWHU→([LW→([LW→([LW→([LW
Specify other (extra) digits that must be added by the system
to the beginning of the dialed digits when calls are placed on
an identified UDP route:
●
7DEOHV→8'35RXWLQJ→Dial pattern no.→(QWHU→Dial
route no.
→(QWHU→'LJLWV→Press Drop→Dial digits to
add
→ (QWHU→([LW→([LW→([LW→([LW
Specify voice, data, or both for an identified UDP route (use
for routes with pools of PRI or T1 facilities):
●
7DEOHV→8'35RXWLQJ→Dial pattern no.→(QWHU→Dial
route no.
→(QWHU→'DWD→Select capability→(QWHU→
([LW→([LW→ ([LW→([LW
