MERLIN LEGEND Communications System Release 6.1

Feature Reference

555-661-110

Issue 1

August 1998

Sample Reports

Page F-32Switch 56 Data Information Report

805 908555100401 9085551004

806 908555100501 9085551005

807 908555100601 9085551006

808 908555100701 9085551007

Switch 56 Data Information Report 55

Print Menu Option: 6ZLWFK

Dial Plan Routing for Network Service

Expected Digits: 3

Digits to Delete: 0

Digits to Add: 0

Trk ss/pp Dirction InType OutType AnsSup Discnt Inmode Outmode Service

801 02/01 2 Way Wink Wink 120 180 T-Tone T-Tone TIE

802 02/02 Outgoing Delay Delay 160 180 Rotary T-Tone S56

803 02/03 Incoming Auto Auto 100 140 Rotary Rotary S56

808 02/08 2 Way Wink Wink 120 180 Rotary Rotary TIE
