Features
Page 662System Renumbering
* LDN (QCC Queue)
† Remote Access
Figure 44. 2-Digit Numbering Plan
NOTE:
Extension numbers 0 and 10 both refer to the same operator position in the
2-Digit Numbering Plan.
Each of the first 57 extension jacks defaults to a 2-digit extension number
beginning with 10 and ending with 66. The rest of the extensions (extension jacks
67–200) are assigned the 4-digit extension numbers 6700 through 6842.
The extension numbers (710–766) shown for Multi-Function Modules are
reserved for MLX extension jacks. These numbers are automatically assigned by
the system to adjuncts connected to MLX telephones either using MFMs (such as
modems, answering machines, or fax machines) or directly (for example, a
terminal adapter). For the first 57 digital extension jacks (numbered 10–66), the
extension number assigned to the adjunct is the extension number assigned to
the MLX telephone, preceded by a 7. For example, if the extension number
assigned to an MLX telephone is 25, the extension number for the MFM adjunct
on that telephone is 725. In this example, a call can be made to the telephone by
dialing
 ,  or to the adjunct by dialing .
Additional extension jacks are shown in Figure 44
as Extra Extensions
(6700–6842), and additional MFMs are shown as Extra Adjuncts (6850–6992). If
extra extensions are assigned, the extension numbers for extra adjuncts are
assigned by the system to MFM adjuncts. The extension number assigned to the
0 Operator Console (not flexible) 0
1 Extensions 10–19
2 Extensions 20–29
3 Extensions 30–39
4 Extensions 40–49
5 Extensions 50–59
6 Extensions
60–66
Extra Extensions
6700–6842 6843–6849
Extra MFMs/
Terminal
Adapters
6850–6992 6993–6999
7 Main Pool
70
Adjuncts
710–766
767– 769
Calling Groups
770–791,7920–7929
Paging Groups
793–799
8
800*
Lines/Trunks
801–880
Park
881–888
889†
Pools
890–899
9 ARS Access (Hybrid/PBX Mode)/Idle Line Access 9
