MERLIN LEGEND Communications System Release 6.1
Feature Reference
555-661-110
Issue 1
August 1998
Features
Page 687Touch-Tone or Rotary Signaling
Touch-Tone or Rotary Signaling 43
At a Glance 43
Description 43
Touch-tone, tip/ring devices, such as single-line telephones or fax machines, are
equipped with a dialpad that generates dual-tone multifrequency (DTMF) signals
when a dial button is pressed. Analog multiline and MLX telephones are equipped
with dialpads that generate digitally coded signals when a dial button is pressed.
The duration of the signal sent is 50 milliseconds (50 ms) and is not adjustable.
A touch-tone receiver (TTR) is required either to make calls from tip/ring
equipment or to use the Remote Access feature. TTRs are provided on 400 (LS),
400 GS/LS, 800 DID, 008 OPT, 800 GS/LS-ID, 016 (T/R), and 012 modules.
Normally, these TTRs are sufficient to handle the calls originated from these
modules. However, additional TTRs may be needed to support the following
services:
■ Tie trunks and T1-emulated tie trunks set for DTMF signaling
■ Tandem tie trunks and T1-emulated tandem tie trunks used in a private
network (Release 6.0 and later systems)
■ Remote Access
Users Affected Telephone users, operators
Reports Affected DID Trunk Information, GS/LS Trunk Information, System
Information (
6\V6HWXS), Tie Trunk Information
Modes All
Telephones All
System Programming Change individual line/trunk to rotary or touch-tone service:
●
/LQHV7UXQNV→77/6'LVF→2XWPRGH
Change individual tie trunk to rotary or touch-tone service:
●
/LQHV7UXQNV→7,(/LQHV→,QPRGH
Change individual tie trunk to rotary or touch-tone service:
●
/LQHV7UXQNV→7,(/LQHV→2XWPRGH
Change DID trunk block to rotary or touch-tone signaling:
●
/LQHV7UXQNV→','→6LJQDOLQJ
Change rotary signaling:
●
2SWLRQV→More→5RWDU\→'HOD\1R'HOD\
Factory Settings
DID
Loop-Start/Ground-Start
Tie
Rotary Signaling
Rotary
Touch-tone
Rotary
Delay
