Lucent Technologies MERLIN LEGEND Release 6.1 User Manual

MERLIN LEGEND Communications System Release 6.1
Feature Reference 555-661-110
Issue 1
August 1998
Applications
Page I-19Messaging 2000
I
NOTES:
1. The system treats the MERLIN LEGEND Mail module as a 012
module. It uses a maximum of seven ports, up to six VMI ports and one
RMD port (port 7); ports 8 through 12 are not installed. Module ports
cannot be used as standard extensions; you cannot plug any
equipment into them. The system assigns 12 extension numbers to the
module as a default.
2. The system may require additional TTRs to allow the MERLIN
LEGEND Mail module to handle a large number of voice connections.
Two TTRs are provided on the MERLIN LEGEND Mail module, two
TTRs on the 012 module, and four on the 016 (T/R) module. For details
about TTR requirements, see Table 62, page I–19
.
Required Voice Messaging Interface (VMI) Ports 61
The number of required VMI ports depends on the number of incoming
lines/trunks, the number of subscribers programmed for Automated Attendant
service, and the number of busy-hour calls. Table 62
lists these requirements.
Table 62. Ports Required for MERLIN MAIL and MERLIN LEGEND Mail
Voice Messaging Systems
Messaging 2000 62
Messaging 2000 is a voice messaging system that consists of a standalone PC
containing ports for voice and fax mail. The system offers flexibility for the small-
and mid-sized business, ranging from 4 to 16 voice-processing ports and 2 to 4
fax-processing ports. A total storage capacity of 60 hours is provided.
The voice messaging capabilities include:
■ Automated Attendant
■ Call handling
■ Voice mail
■ Fax mail
■ Windows-based graphic user interface of a user’s voice mail (optional)
No. of VMI Ports
Required Incoming Lines/Trunks
No. of Subscribers or
Busy-Hour Calls
2 1 to 6 1 to 20
4 7 to 18 21 to 60
6 19 and up 61 and up
