Features

Page 166Coverage

Table 9. Group Coverage Call Delivery Rules (Release 4.0 and Prior Systems)

= Coverage delay interval

= Delay Ring interval

* Ringing is delayed an additional

after the green LED turns on at a Group Cover button

programmed for Delay Ring on a multiline telephone.

Receiver Type Sender Status

Individual Coverage

Receiver Status

Call Delivered to Group

Coverage after...

Group Cover

button(s) only or

Group Cover

button(s) and QCC

queue

Available Available

Unavailable or

unassigned

CD + DR

Immediate*

Unavailable Available

Unavailable or

unassigned

CD + DR

Immediate*

QCC Queue only or

Calling group only

Available Available

Unavailable or

unassigned

CD + DR

Unavailable Available

Unavailable or

unassigned

CD + DR

Immediate*
