MERLIN LEGEND Communications System Release 6.1
Feature Reference
555-661-110
Issue 1
August 1998
Features
Page 227Direct Station Selector
Extension Status Operation (Hotel Configuration)
When Extension Status is in Hotel configuration, the Extension Status feature is
assigned to and removed from individual DLCs through system programming (see
“Extension Status” on page 280
for details). Hotel Extension Status operation is
always active, unless the operator presses the Message Status button to use the
Auto Dial or DSS buttons to see message-waiting status for each extension.
Pressing a DSS button while in Hotel Extension Status operation has the same
effect as for normal call-handling operations.
When not in Message Status operation, the red LED next to each DSS button for
a room extension is used to monitor room availability, and the DSS button is used
to restrict the extensions when the rooms are not occupied.
In Release 6.1 and later systems, Extension Status Operation is available only for
local extensions.
The meaning of the red LED next to the DSS button for each room is shown in
Table 15
.
Table 15. LED Meanings for Hotel Extension Status Operation without Message Status
Active
NOTE:
The LED next to the DSS button for all other types of extensions is always
off and has no meaning.
Message Status Operation
Message Status operation activates when an operator presses the Message
Status button (the lower left feature button on the first DSS) while in normal
call-handling, calling group, CMS supervisory, or Extension Status operation. The
green LED next to the Message Status button is on when Message Status
operation is active.
LED Status
Extension
Status Meaning
Off 0 The room is occupied, and the extension is in regular
call-handling state.
On
■
2 The room is vacant and available for occupancy, and outside
calls cannot be made from the extension.
Slow flashing 1 The room is vacant and ready for cleaning. Outside calls
cannot be made from the extension.
