MERLIN LEGEND Communications System Release 6.1
Feature Reference
555-661-110
Issue 1
August 1998
Features
Page 244Directories
To scroll through the listings, select either

1H[W3DJH to display the next seven
entries or

3UHY3DJH to display the previous seven entries. To display the
telephone number associated with an individual listing, select

6KRZ1XPEHU from
the display—
6KRZ1XPEHU is highlighted—and press the button next to the listing.
To exit the Show Number function, select

6KRZ1XPEHU again—the highlight is
removed from
6KRZ1XPEHU. To dial a number for a listing shown on the display,
press the button next to the listing.
To use the Personal Directory on an MLX-20L telephone, press the Home button;
a QCC operator selects
'LUHFWRU\

from the Home screen. If listings have been
programmed to appear on the Home screen, the first eight listings (six listings for
a QCC operator) are shown. To see the second eight listings (six listings for a
QCC operator), select

1H[W3DJH. To select listings by using a range of letters,
select

1H[W3DJH from the Home display
twice
. Use the same procedure to
search for listings as you do for System and Extension Directories. To dial a
number for a listing shown on the display, press the button next to the listing.
NOTES:
1. The number for a marked Personal Directory listing is displayed when
you choose
6KRZ1XPEHU. A marked Personal Directory listing is
specifically designated during programming to suppress the telephone
number from the display when the number is dialed from the display.
2. Marked System Speed Dial entries (entries that do not display) are not
affected by the Second Dial Tone setting. If a marked System Speed
Dial entry uses star codes and the central office does not immediately
supply dial tone when a star code is entered, the appropriate number
of pauses (1.5 seconds each) must be programmed after each star
code in the entry.
MLX-28D, MLX-16DP, MLX-10DP, MLX-10D, and MLX 5-D Telephones
To use the System or Extension Directory, press the Menu button, select
'LUHFWRU\ from the display, then select either type of directory from the display. To
begin searching, spell the name of the directory entry by using the dialpad. For
example, to spell
Wayne
, dial 

and select (QWHU from the display; the name
with the closest match is displayed.
Scroll through the listings by selecting
3UHY (previous listing) or 1H[W (next listing).
To start a new search, select

1HZ. To dial the number for the name currently
shown on the display, select
'LDO, and the number is automatically dialed. If the
display of the telephone number has not been suppressed,
! appears on the far
right of the display. To see the number, press the More button.
Single-Line Telephones
Single-line telephone users cannot use the Extension Directory feature or the
Personal Directory feature, but can dial the listings in the System Directory by
dialing the System Speed Dial codes assigned to the listings.
