MERLIN LEGEND Communications System Release 6.1
Feature Reference 555-661-110
Issue 1
August 1998
Features
Page 570Recall/Timed Flash
Telephone Differences 39
Queued Call Consoles 39
A QCC cannot use Recall. A Recall button cannot be programmed on the QCC,
nor can the QCC use the Recall feature code.
Other Multiline Telephones 39
Analog multiline BIS telephones have a fixed Recall button that can be pressed to
access the Recall feature.
MLX and cordless/wireless telephone users can use Recall by pressing the
Feature button and dialing
, but it is recommended that a Recall button be
programmed instead.
To activate host system features in Behind Switch mode, the fixed Conf, Drop,
and Transfer buttons on an MLX or analog multiline telephone must be
programmed, through system programming, to send a timed flash plus the code
expected by the host. Once this programming is done, these fixed buttons have
no effect when pressed during an inside call.
If use of the communications system’s Conference, Drop, and Transfer features is
also desired in Behind Switch mode, they must be programmed on available line
buttons on each multiline telephone, using either extension programming or
centralized telephone programming.
Single-Line Telephones 39
A single-line telephone user without a Recall or Flash button must use the
switchhook to send a timed flash. The communications system intercepts the
signal; if it is to be sent on to a host switch, the system sends a signal of the
duration programmed for the Recall timer.
In Hybrid/PBX or Key mode, a Recall signal from a single-line telephone accesses
the communications system’s Hold, Conference, and Transfer features.
In Behind Switch mode, a Recall signal from a single-line telephone is ordinarily
sent to the host switch because the factory setting for the ALS sequence selects
the prime line. However, if the ALS sequence is changed to select an ICOM button
and an Idle Line Access code initiates a call, the Recall signal accesses the
communications system’s Hold, Conference, and Transfer features, not those of
the host switch.
NOTES:
1. If a single-line telephone with a timed or positive disconnect is used,
pressing the switchhook disconnects the call. With this type of
telephone, the Recall or Flash button must be used instead of the
switchhook for features that require a switchhook flash.
