MERLIN LEGEND Communications System Release 6.1

Feature Reference

555-661-110

Issue 1

August 1998

Features and Planning Forms

Page B-10

Feature Planning Forms

Transfer 1—System Planning

6a—Optional Operator Features

8a—System Features

Button diagrams on all appropriate telephone forms

Uniform Dial Plan (UDP)

Routing

Refer to Non-Local UDP Administration Form in the Installation

Specification

Voice Announce to Busy 4b—Analog Multiline Telephone

4d—MLX Telephone

5a—Direct-Line Console (DLC): Analog

5b—Direct-Line Console (DLC): Digital

Data Form 1a—Modem Data Station

Data Form 1b—ISDN Terminal Adapter Data Station

Data Form 3—Digital Data/Video Station

Data Form 2—Data Hunt Group

5d—Queued Call Console (QCC)

Volume Not Applicable
