MERLIN LEGEND Communications System Release 6.1

Feature Reference

555-661-110

Issue 1

August 1998

Sample Reports

Page F-9Dial Plan Report

Dial Plan Report—Continued 55

DIAL PLAN FOR STATIONS

STN #: 1 10 OPERATR STN #: 2 710

STN #: 3 11 STN #: 4 711

STN #: 5 12 STN #: 6 712

STN #: 7 13 EXT 13 STN #: 8 713

STN #: 9 14 EXT 14 STN #: 10 714

STN #: 11 15 STN #: 12 715

STN #: 13 16 STN #: 14 716

STN #: 15 17 STN #: 16 717

STN #: 17 18 EXT 18 STN #: 18 19

STN #: 19 20 STN #: 20 21

STN #: 21 22 OPERATR STN #: 22 23

STN #: 23 24 STN #: 24 25

STN #: 25 26 STN #: 26 21

STN #: 27 28 STN #: 28 29

STN #: 29 30 AUDIXVP STN #: 30 31 AUDIXVP

STN #: 31 32 AUDIXVP STN #: 32 33 AUDIXVP

STN #: 33 34 STN #: 34 35

STN #: 35 36 STN #: 36 31

STN #: 37 38 STN #: 38 39

STN #: 39 40 STN #: 40 41

STN #: 41 42 EXT 42 STN #: 42 742

STN #: 121 7198 STN #: 122 7398

STN #: 123 5555 STN #: 124 7399
