MERLIN LEGEND Communications System Release 6.1

Feature Reference

555-661-110

Issue 1

August 1998

Button Diagrams

Page G-5

Figure 53. MLX 5- and 10-Button Telephone Button Diagram (Key and Behind

Switch Modes)

Icom

Voice

Icom

Ring

Behind Switch Mode:

One prime line is assigned

to button 3

Default Chapter3
