MERLIN LEGEND Communications System Release 6.1
Feature Reference 555-661-110
Issue 1
August 1998
Applications
Page I-64Picasso Still-Image Phone
I
■ Optional real-time annotation using a Windows-compatible annotation
device such as a mouse
■ Windows interface software
■ Support for required customer-supplied input device
■ Support for required customer-supplied monitor
Considerations and Constraints 67
Image transmission requires 5 to 40 seconds.
The customer supplies a required input device and monitor.
Both parties on a call must have a Picasso Still-Image Phone.
Platform Requirements 67
The Picasso Still-Image Phone connects to a port on a 016 (T/R) or 012 module
and uses any analog central office line/trunk. Depending upon the configuration
and optional features required, the following components may be needed:
■ Windows version 3.1 or higher
■ A replacement handset
■ An annotation device
■ A TV monitor or LCD monitor (required)
■ A customer-supplied camcorder, electronic camera, document camera,
VCR, or photo CD player as an input device (required)
■ An AC power supply with power supply cord (required)
■ An RCA video cable
■ A 4-pin mini DIN video cable
■ A BNC-RCA adapter
■ An RF modulator
■ An F connector cable
■ A 6-outlet power strip
