Maeda MC815C - Page 10

viii
Item
Page
SEARCHER HOOK
389
1. CAUTIONS IN USING SEARCHER HOOK 390
2. SEARCHER HOOK SAFETY LABEL LOCATIONS 391
3. NAMES OF SEARCHER HOOK PARTS 394
4. MOUNTING AND STOWING SEARCHER HOOK 395
4.1 MOUNTING SEARCHER HOOK 396
4.2 STOWING SEARCHER HOOK 399
4.3 REMOVING SEARCHER HOOK (CHANGING TO STANDARD SPECIFICATION) 401
4.3.1 REMOVING SEARCHER HOOK BOOM 401
4.3.2 REMOVING BRACKET 402
4.4 MOUNTING SEARCHER HOOK (CHANGING TO SEARCHER HOOK SPECIFICATION) 403
4.4.1 MOUNTING SEARCHER HOOK BOOM 403
4.4.2 ATTACHING BRACKET 404
5. HANDLING MONITOR AND MOMENT LIMITER 405
5.1 NAME OF MONITOR DISPLAY 405
5.1.1 MONITOR DISPLAY IN SEARCHER HOOK MODE 405
5.1.2 CHANGING SEARCHER HOOK MODE 407
5.2 MOMENT LIMITER FUNCTIONS 408
5.3 RECOVERY OPERATION FROM AUTOMATIC STOP 408
6. OPERATION 409
6.1 CHANGING SEARCHER HOOK ANGLE 409
7. TROUBLESHOOTING 410
8. INSPECTION AND MAINTENANCE 411
8.1 PRE-OPERATION INSPECTION 411
9. SPECIFICATION 412
9.1 SPECIFICATION TABLE 412
9.2 SPECIFICATION DIMENSIONAL DRAWING 412
9.3 RATED TOTAL LOAD CHART 413
9.4 WORKING RADIUS/LIFTING HEIGHT 414
