130
1.8 RADIATOR COVER
• Before removing the radiator cover, be sure to stop the engine and remove the key
from the starter switch.
• Do not remove the radiator cover immediately after operation while the engine is still
hot.
[1] REMOVING RADIATOR COVER
Remove the radiator cover with the following procedure
when performing inspection/maintenance inside the
radiator cover.
1. Remove the fixing bolts (2) (4 bolts) of the radiator
cover (1).
2. Remove the radiator cover (1).
[2] INSTALLING RADIATOR COVER
When you are finished with inspection/maintenance inside the radiator cover, install the radiator
cover in the following procedure:
1. Put back the radiator cover (1) into place.
2. Securely tighten the fixing bolts (2) (4 bolts) of the radiator cover (1).
