Maeda MC815C - Inspection of Outrigger Extension Position; Checking Engine Exhaust Gas Colour, Noise and Vibration

284
[6] INSPECTION OF OUTRIGGER EXTENSION POSITION
Start the engine and extend the outriggers to “medium”
and “maximum” positions, and check if the monitor
display of the moment limiter is correct.
NOTES
To adjust the outrigger extension, check the sticker
(medium, maximum) on the top side of inner box.
[7] CHECKING ENGINE EXHAUST GAS COLOUR,
NOISE AND VIBRATION
1. Release the acceleration pedal (6) to low idling position
so that the engine is kept in no load operation for 5
minutes.
2. Verify that the engine exhaust gas color is either
transparent or slightly blue. Also, check for abnormal
noises and vibrations.
Repair if any abnormality is found.
