385
9. SPECIFICATION
9.1 SPECIFICATION TABLE
CAUTION
In this section, only the specifications for the fly jib specification different from standard
specification are described.
For other specifications, see “Specification” section.
Equipment / Item MC815C FLY-JIB
Weight and
dimensions
Body mass 9950 kg
Overall length × width × height 6200 mm × 1740 mm × 2490 mm
9.2 SPECIFICATION DIMENSIONAL DRAWING
