412
9. SPECIFICATION
9.1 SPECIFICATION TABLE
CAUTION
In this section, only the searcher hook specification, different from the standard specification is
described.
For other specifications, see “Specification” section.
Equipment / Item MC815C SEARCHER HOOK
Weight and
dimensions
Body mass 9520 kg
Overall length × width × height 6550 mm × 1670 mm × 2490 mm
9.2 SPECIFICATION DIMENSIONAL DRAWING
To Next Page
