[5] OUTRIGGER STOWAGE OPERATION
Standard operating procedures/
Machine conditions
Indication and Alarm
Operation of safety
devices
Implementing outrigger stowage
operation
1. Implementing outrigger
ground stowage operation
• Selecting outrigger mode
• Turning on outrigger switch
• Outrigger grounding lamp (red)
blinks
[Tricolor revolving light (red)
lights up.]
Crane Interlock
• If any one of the 8
lamps, outrigger
extension lamps and
outrigger grounding
lamps, does not light
up (in green), all
outrigger operations
are brought to a stop.
2. Implementing extension
stowage
• Outrigger extension switch
[ON]
• Slewing (stowing) outrigger
rotaries and securing them
with positioning pins
• Engine shutdown
• Outrigger extension lamp (red)
blinks
[Tricolor revolving light (red)
lights up.]
When the machine tilts at an
angle of 3 degrees or more
during outrigger stowage
operation
• Alarm buzzer constantly
sounds
Machine tilt detection
device activates
[6] MACHINE TRAVELLING OPERATION
Standard operating procedures/
Machine conditions
Indication and Alarm
Operation of safety
devices
Implementing travel control
• Selecting Travel mode
• Starting engine
• Manipulating operation levers
When the machine tilts at an
angle of 15 degrees or more
while driving machine
• Alarm buzzer constantly
sounds
Machine tilt detection
device activates
