159
9. When the machine is raised up to a height of about
50 mm from the ground, adjust the machine so
that the machine is in a horizontal position while
checking the position of the yellow bubble in the
leveling instrument. At this point, if “automatic” is
selected for the mode selection switch (3), the
machine is automatically leveled so that it is in
horizontal condition.
10. When you are finished setting all outriggers, set all
outrigger switches to the “NEUTRAL” position.
11. Make sure that all of the four outrigger grounding lamps
(3) on the monitor are lit in yellow.
NOTES
All of the crane stowage lamp (1), the four outrigger
extension lamps (2) and four outrigger grounding lamps
(3) are lit in yellow.
CAUTION
If any of the outrigger grounding lamps (3) are
blinking red, remove the cover (7) of the outrigger
adapters (6) part and check them for foreign materials
being caught in the bend sections.
